Binding Force Adjustable Automatic Threading Cable Tie Machine For Zip Ties 80mm Length
The machine is different with the traditional cable tie tool. It could automatically thread, tighten and cut off cable ties once you tread the pedal. This automatic threading cable tie machine SWT25080F uses loose cable ties W2.5mm * L80mm * T1.1mm.
SWT25080F advantages
1. Automatic threading, tightening, cutting off cable ties and collecting the excess tail into a plastic box.
2. Cable tie gun could be fixed near the assembly line. Worker can hold the items by two hands and tread the pedal to finish binding.
3. Bundling one cable tie takes about 0.7S normally.
4. The tension forces are adjustable.
5. PLC control system and touch screen.
6. You could set the quantity of cable ties bundled and the machine could record the actual number.
7. Be suitable for the wires with PVC sleeve, or bags sealed.
SWT25080F base data
| 1 | Description | The machine could automatically thread and tighten cable ties. | |
| 2 | Brand | SWIFT | |
| 3 | Model | SWT25080F | |
| 4 | Cable ties details | Type | Bulk cable ties |
| Model | T25080 | ||
| Width | 2.5mm | ||
| Length | 80mm/3.14inch | ||
| Thickness | 1.1mm | ||
| Tensile strength | 8kg | ||
| Quantity/bags | 1,000pcs | ||
| 5 | Usage/per time in vibration bowl | 300pcs enough | |
| 6 | Product Dimension | Bundle ø max. | 14mm |
| Bundle ø min. | 2mm | ||
| 9 | Bundling speed | 1.0S | |
| 10 | Cable tie gun details | Power | DC48V auto switch |
| Size | L27 * W24 * T15cm | ||
| Tension forces | Adjustable by turn knob | ||
| 11 | Power supply | AC110V/220V, 50/60Hz | |
| 12 | Pneumatic pressure | 5kg/cm² | |
| 13 | Max Power | 1,000W | |
| 14 | Certificates | CE and RoHS certified. | |
Applications
| Home appliance | Wire harness inside fan, air conditions, fridge |
| Auto industry | Auto oil pipes |
| Food industry | Bags sealed, the food label fixed, crab claws bundled |
| Offshore fishery | Fishing net |
| Moto coil industry | Fixing wires led out of motor stator, motor coil |
Trade terms
1. Payment: 100%TT payment before shipment.
2. Lead time: 10 - 15working days after receive payment.
3. Shipment: By sea/air/express.
Packing details
| SWT25080F Packing Details | ||
| Export wooden case | 2pcs | |
| The host machine / wooden case | G.W./kg | 100.5kg |
| Packing Size/cm | L74 * W71 * H84cm | |
| The vibration bowl / wooden case | G.W./kg | 67kg |
| Packing Size/cm | L68 * W54 * H92cm | |
| Total G.W. | 166.5kg( estimated) | |
FAQ
1. Are you a factory?
Yes, we have our factory in Shenzhen and have strong R and D department. ODM is welcomed.
2. Can I buy a cable tie gun only?
No, it is not useful to buy a cable tie gun only. That is because loose cable ties are transferred into the gun by the host machine.
3. Do I need to wrap cable ties?
No, the machine would wrap, tighten cable ties until the preset tension force is reached. And it would cut off the excess tails.
